Alloy 20, also known as Carpenter 20 and Incoloy 20 offers users a wide variety of benefits including:Excellent resistance to corrosion, crevice corrosion, and pitting
Perfect for use around sulfuric, phosphoric, and nitric acids
Ease of fabrication and elevated mechanical properties
Available in flat bar, forging stock, hexagon, plate, pipe, sheet, strip, round bar, tube, and wire, Alloy 20 can be fabricated to produce:
Mixing Tanks
Heat Exchangers
Process Piping
Pickling Equipment
Pumps, valves, fasteners, and fittings
Alloy 20 meets or exceeds different industry standards including a multitude of ASTM, ASME, ISO, and DIN standards. TIG, MIG, and SAW welding can be used on Alloy 20, and can be formed through hot and cold working.
Alloy 20 has a unique chemical composition:
Fe 31-44% balance
Ni 32.5-35%
Cr 19-21%
Cu 3-4%
Mo 2-3%
Due to its high nickel content (32-38%), there is some disagreement whether Alloy 20 is a nickel or a stainless steel alloy. No matter what side of the discussion you fall on, it is clear that Alloy 20 is an excellent choice for a wide variety of industries and applications. At Jiangsu HYT International, we are proud to stock and sell Nickel Alloy 20, Carpenter® 20, and Incoloy® 20 in all of the popular sizes and forms.
Tip: Click the 'Alloy 20 Products' product details tag to find out specific Alloy 20 product HYT can offer and their size, thickness, etc.
| Element | Content (%) |
| Iron, Fe | 35 |
| Nickel, Ni | 32-38 |
| Chromium, Cr | 19-21 |
| Copper, Cu | 3-4 |
| Manganese, Mn | ≤2 |
| Molybdenum, Mo | 2-3 |
| Niobium, Nb | ≤1 |
| Silicon, Si | ≤1 |
| Carbon, C | ≤0.07 |
| Phosphorous, P | ≤0.045 |
| Sulfur, S | ≤0.035 |
| Properties | Metric | Imperial |
| Density | 8.05 g/cm3 | 0.291 lb/in3 |
| Properties | Metric | Imperial |
| Tensile strength (annealed) | 620 MPa | 89900 psi |
| Yield strength (annealed) | 300 MPa | 43500 psi |
| Elongation at break (annealed) | 41% | 41% |
| Properties | Metric | Imperial |
| Thermal expansion co-efficient (@20-100°C/68-212°F) | 14.7 µm/m°C | 8.17 µin/in°F |
| Thermal conductivity | 12.3 W/mK | 85.4 BTU.in/hrft².°F |
Nickel Alloy 20, Carpenter 20 and Incoloy 20 Standards
| Rod, Bar, Wire, Forging Stock | ASTM B 462 ASTM B 472 ASTM B 473 ASME SB 472 ASME SB 473 ISO 9723 ISO 9724 ISO 9725 DIN 17752-17754 |
| Plate, Sheet, Strip | ASTM A 240 ASTM A 480 ASTM B 463 ASTM B 906 ASME SA 240 ASME SA 480 ASME SB 463 ASME SB 906 ISO 6208 DIN 17750 |
| Pipe and Tube | ASTM B 729 ASTM B 829 ASTM B 468 ASTM B 751 ASTM B 464 ASTM B 775 ASTM B 474 ASME SB 729 ASME SB 829 ASME SB 468 ASME SB 751 ASME SB 464 ASME SB 775 ASME SB 474 ISO 6207 DIN 77751 |
| Other | DIN 17744 ASTM B 366 ASTM B 462 ASTM B 471 ASTM B 475 ASME SB 366 ASME SB-462 ASME SB 471 ASME SB 475 |
Tip: Click the 'Alloy 20 Products' product details tag to find out specific Alloy 20 product HYT can offer and their size, thickness, etc.
